Emerson ACP15034CD APPLETON 150A CLAMP RING PLUG 3W4P ST2 ACP15034CD

Product Description

The Appleton Powertite ACP15034CD is a clamping ring plug designed for three-phase grounding. It operates at a voltage range of 250 to 600 VAC/VDC and supports a current rating of 150 amperes. This plug is suitable for various applications such as motor generator units, welders, pumps, and portable or fixed electrical equipment.

• 4 poles and 3 wires configuration
• Temperature rated from -40 to 225 degrees Fahrenheit
• NEMA Rating 3/3R/4/4X for outdoor use

Product Highlights

This plug features a neoprene bushing that is resistant to water entry and hydrocarbon deterioration. It is built for robust performance in harsh environments.

Product Information

Standard Information

• Manufacturer: Emerson Electric
• UPC: 78138109857

Technical Specifications

• Amperage Rating: 150 A
• Dimensions: 10-1/2 inches L x 4-1/4 inches W
• Frequency Rating: 50/400 Hz
• Material: Copper Free Aluminum
• NEMA Rating: NEMA 3/3R/4/4X
• Number of Poles: 4
• Number of Wires: 3
• Temperature Rating: -40 to 225 degrees Fahrenheit
• Voltage Rating: 250/600 VAC/VDC
