Emberglow EWPO2430PM Vent Free Lp Burner 33000 Btu/h

Product Description

The EMBERGLOW EWPO2430PM is a vent-free liquid propane burner system designed for installation in vent-free fireboxes in residential and mobile home applications. Rated at 33,000 BTU/h maximum output, it uses a manual valve for operation and does not support remote control of any kind — all adjustments are made directly at the burner inside the firebox. The system includes an Oxygen Depletion System (ODS) that shuts off gas flow automatically when room oxygen levels drop to unsafe levels. Manifold pressure is 8.0 inches water column, with inlet supply pressure ranging from 11.0 to 14.0 inches water column. A licensed gas technician should perform installation in accordance with applicable local codes.

This burner is intended for indoor use in single-sided vent-free fireboxes. It is certified for use in mobile homes. It accommodates 18-inch, 24-inch, and 30-inch Everwarm Palmetto and Low Country Timber log sets. Minimum firebox requirements vary by log size: an 18-inch log set requires a firebox at least 17 inches tall, 13.5 inches deep, 24 inches wide at the front, and 20.5 inches wide at the rear. A 24-inch log set requires the same height and depth with a 28-inch front width and 20.5-inch rear width. A 30-inch log set requires a 32-inch front width and 26-inch rear width. Due to the maximum BTU output of this burner, it cannot be used in the following Monessen fireboxes: ACUF32-BD, ACUF32-GD, BUF32A, BUF32-T, BUF32-H, LCUF32CR-C, LCUF32CR-BT, LCUF32CR-GT, or LCUF32CR-GH.

Key Features

• 33,000 BTU/h maximum output on liquid propane
• Oxygen Depletion System (ODS) shuts off gas automatically at unsafe oxygen levels
• Manual valve control only — no remote capability
• Compatible with 18-inch, 24-inch, and 30-inch Everwarm Palmetto and Low Country Timber log sets
• Certified for mobile home installation
• 1/2-inch gas connection for standard LP supply lines

Compatibility

Certified for use with specific Everwarm Palmetto and Low Country Timber log sets in 18-inch, 24-inch, and 30-inch sizes only. Burners are not universal — use only with certified compatible log sets to prevent fire, carbon monoxide poisoning, and property damage. Cannot be installed in Monessen fireboxes ACUF32-BD, ACUF32-GD, BUF32A, BUF32-T, BUF32-H, LCUF32CR-C, LCUF32CR-BT, LCUF32CR-GT, or LCUF32CR-GH. Vent-free products cannot be shipped to the state of California. State and local codes in some areas prohibit vent-free installations — verify local building codes before ordering or installing.

Installation Notes

Installation must be performed by a qualified gas technician in compliance with applicable local and national codes, including NFPA 54 and any local amendments. Shut off the LP supply at the tank and verify zero pressure at the connection point before beginning any work. Confirm firebox dimensions meet the minimum requirements for the selected log set size before installation. Vent-free appliances require adequate room ventilation — do not install in undersized or sealed spaces without verifying airflow requirements per local code.

Technical Specifications

• Fuel Type: Liquid Propane (LP)
• Maximum BTU Output: 33,000 BTU/h
• Ignition Type: Manual (no remote)
• Venting Type: Vent Free
• Allowable Log Set Sizes: 18 inches, 24 inches, 30 inches
• Gas Connection Size: 1/2 inch
• Manifold Pressure: 8.0 inches water column
• Inlet Gas Pressure Minimum: 11.0 inches water column
• Inlet Gas Pressure Maximum: 14.0 inches water column
• Location of Use: Indoor
• Fireplace Style: Single Sided
• Certified Usage: Mobile Home Approved

Standard Information

• Brand: EMBERGLOW
• Manufacturer Part Number: EWPO2430PM
