Emberglow EWPO2430NM Vent Free Natural Gas Burner 35000 Btu/h

Product Description

The EMBERGLOW EWPO2430NM is a vent-free natural gas burner designed for installation in a vent-free firebox as part of a log set system. Rated at 35,000 BTU/h maximum output, this manual valve burner is controlled directly at the burner unit inside the firebox and is not compatible with any remote operation. It includes an Oxygen Depletion System (ODS) that automatically shuts off the gas supply when room oxygen levels fall to unsafe levels, providing a critical safety layer for indoor use. Manifold pressure is 3.5 inches w.c., with inlet supply pressure ranging from 5.0 inches w.c. minimum to 10.5 inches w.c. maximum. Installation is performed by a licensed gas technician.

This burner is approved for indoor, single-sided fireplace installations and is certified for use in mobile homes. It accepts 18-inch, 24-inch, and 30-inch log sets from the Everwarm Palmetto and Low Country Timber series. Minimum firebox requirements vary by log size: an 18-inch log requires a firebox at least 17 inches high, 13.5 inches deep, 24 inches front width, and 20.5 inches rear width. A 24-inch log requires the same height and depth with 28 inches front width and 20.5 inches rear width. A 30-inch log requires 17 inches height, 13.5 inches depth, 32 inches front width, and 26 inches rear width. Due to its maximum BTU rating, this burner cannot be used in the following Monessen fireboxes: ACUF32-BD, ACUF32-GD, BUF32A, BUF32-T, BUF32-H, LCUF32CR-C, LCUF32CR-BT, LCUF32CR-GT, or LCUF32CR-GH.

Key Features

• 35,000 BTU/h maximum output for vent-free natural gas operation
• Oxygen Depletion System (ODS) automatically shuts off gas when oxygen drops to unsafe levels
• Manual valve control only — no remote capability
• Accepts 18-inch, 24-inch, and 30-inch compatible log sets
• Certified for mobile home use
• 1/2-inch gas connection for standard supply line hookup

Compatibility

Compatible with 18-inch, 24-inch, and 30-inch Everwarm Palmetto and Low Country Timber log sets only. Burners are certified to work with specific log sets and are not universal — use with a non-compatible log set creates serious risk of fire, carbon monoxide poisoning, and property damage. Cannot be installed in Monessen fireboxes ACUF32-BD, ACUF32-GD, BUF32A, BUF32-T, BUF32-H, LCUF32CR-C, LCUF32CR-BT, LCUF32CR-GT, or LCUF32CR-GH.

Installation Notes

Installation must be performed by a licensed gas technician in accordance with local building codes and the applicable provisions of ANSI Z21.11.2 and NFPA 54. Shut off the gas supply at the main valve before any service or installation work. Vent-free products are prohibited in California and may be restricted by state or local codes in other jurisdictions — verify local regulations before ordering or installing. Never use this burner with a log set that is not explicitly listed as compatible.

Technical Specifications

• Fuel Type: Natural Gas (NG)
• BTU Output (Max.): 35,000 BTU/h
• Ignition Type: Manual (No Remote)
• Venting Type: Vent Free
• Manifold Pressure: 3.5 inches w.c.
• Inlet Gas Pressure (Min.): 5.0 inches w.c.
• Inlet Gas Pressure (Max.): 10.5 inches w.c.
• Gas Connection Size: 1/2 inch
• Allowable Log Set Sizes: 18 inches, 24 inches, 30 inches
• Fireplace Style: Single Sided
• Location of Use: Indoor
• Certified Usage: Mobile Home Approved

Standard Information

• Brand: EMBERGLOW
• Manufacturer Part Number: EWPO2430NM
