Elkhart Products 9043400CB Copper 45 Elbow 2.5 in

Product Description

The ELKHART PRODUCTS 9043400CB is a 2.5-inch copper 45-degree pressure elbow supplied cleaned and bagged for use in potable water, HVAC hydronic, and mechanical piping systems. The cleaned-and-bagged designation means the fitting interior is free of oils and debris at the factory, reducing prep time on the job and meeting cleanliness requirements for medical gas and other sensitive applications. Installed by licensed plumbers and pipefitters, this fitting accepts standard 2.5-inch copper tube and is joined by sweat soldering following accepted brazing or soldering procedures.

This elbow is suited for residential and light commercial applications where a 45-degree directional change is required in a copper piping run. Typical installations include domestic hot and cold water distribution, hydronic heating and cooling loops, refrigeration piping, and general mechanical systems. The cleaned-and-bagged packaging makes it appropriate for medical gas piping applications where ASSE 6010 or NFPA 99 cleanliness standards apply.

Key Features

• 2.5-inch nominal size for standard copper tube systems
• 45-degree elbow geometry for gradual directional change in piping runs
• Factory cleaned and bagged interior — ready for use in clean-service and medical gas applications
• Sweat-solder or braze connection compatible with standard copper tube
• Copper construction provides corrosion resistance and long service life in water and hydronic systems

Compatibility

Designed as an OEM-style pressure fitting for use with standard 2.5-inch copper tube in residential and commercial plumbing, HVAC hydronic, and mechanical piping systems.

Installation Notes

Installation should be performed by a licensed plumber or pipefitter in accordance with local plumbing codes and ASTM B88 copper tube standards. Shut off and drain the system and verify zero pressure before cutting into any existing piping. Clean tube ends and fitting cup with appropriate abrasive cloth or pad and apply flux per the solder or braze material manufacturer instructions before joining. For medical gas applications, follow NFPA 99 procedures and use only personnel qualified under ASSE 6010.

Technical Specifications

• Nominal Size: 2.5 inches
• Fitting Angle: 45 degrees
• Material: Copper
• Connection Type: Sweat (solder/braze)
• Condition: Cleaned and Bagged
• UPC: 039923302953

Standard Information

• Brand: ELKHART PRODUCTS
• Manufacturer Part Number: 9043400CB
