Elkhart Products 45ELL-38 Copper 45 Degree Elbow 3/8 Inch

Product Description

The ELKHART PRODUCTS 45ELL-38 is a 3/8-inch copper 45-degree elbow fitting designed for use in refrigeration, HVAC, and plumbing piping systems. This fitting is cleaned and bagged at the factory, making it ready for use in systems that require contamination-free connections, such as air conditioning refrigerant lines and medical gas installations. The 45-degree angle allows for directional changes in copper tubing runs without the sharper turn of a 90-degree fitting, helping maintain smooth flow and reducing pressure drop in the line.

This elbow is suited for residential and light commercial applications where 3/8-inch copper tubing is used. Common install scenarios include refrigerant suction and liquid line routing, hydronic heating systems, domestic water piping, and ACR (air conditioning and refrigeration) service work. The cleaned and bagged packaging is especially relevant for refrigeration and ACR applications where system cleanliness is a code and manufacturer requirement.

Key Features

• 45-degree bend for gradual directional changes in copper tubing runs
• Cleaned and bagged for contamination-free use in refrigeration and ACR systems
• 3/8-inch size fits standard copper tubing used in HVAC and plumbing applications
• Copper construction provides corrosion resistance and compatibility with solder or braze joining methods

Compatibility

Designed as an OEM-style copper sweat fitting for use with 3/8-inch copper tubing in standard HVAC, refrigeration, and plumbing piping applications.

Installation Notes

Installation is performed by licensed plumbers, HVAC technicians, or refrigeration mechanics using standard sweat soldering or silver brazing techniques. Always recover refrigerant and depressurize the system before cutting into any refrigerant line. Follow applicable codes including ASHRAE 15, IFGC, and local mechanical codes for refrigerant and gas piping work. Maintain the cleaned and bagged condition of the fitting until immediately before installation to prevent contamination of the system.

Technical Specifications

• Fitting Type: 45-Degree Elbow
• Tube Size: 3/8 inches
• Material: Copper
• Preparation: Cleaned and Bagged
• UPC: 1775420301975

Standard Information

• Brand: ELKHART PRODUCTS
• Manufacturer Part Number: 45ELL-38
