Elkhart Products 10046356 CDF2L45 2 DWV 45 ELL REPLACEMENT MPN

Product Description

The Elkhart Products 10046356 is a copper elbow fitting designed for durable plumbing solutions. This fitting has a 45-degree angle and is suitable for both residential and industrial applications. Its two-inch size and female soldered connections provide solid performance for drainage, waste, and vent (DWV) systems.

• Manufactured from high-quality copper
• Pressure rating of three hundred sixty PSI
• Temperature rating of four hundred degrees Fahrenheit

Product Highlights

This fitting is crafted to meet ASME/ANSI standards and is designed for long-lasting service.

Product Information

Standard Information

• Material: Copper
• End Connection: Female Soldered x Female Soldered

Technical Specifications

• Angle: 45 Degree
• Applicable Standard: ASME/ANSI B16.22/B16.29, MSS SP104
• Application: Industrial, Residential, DWV
• Pressure Rating: 360 PSI at -20 to 100 Deg F
• Temperature Rating: 400 Deg F
• Size A: 2 Inch
• Size B: 2 Inch
• Thickness: 0.059 Inch
