Elkay LK940GN04L2H Commercial Faucet Wall Mount 8 Inch Spread 2 Inch Lever ADA Chrome 3-5/8 Inch Gooseneck Length

Product Description

The Elkay LK940GN04L2H is a commercial faucet with wall mount, 8-inch spread, two 2-inch lever handles and is ADA compliant. It features a chrome finish, 3-5/8 inch gooseneck spout length, and 3-5/8 inch spout reach. This faucet has a quarter turn ceramic disc cartridge and solid brass construction.

• Wall Mount
• 8 Inch Spread
• 2 Inch Lever Handles

Product Highlights

This Elkay commercial faucet combines performance and style for various applications, including commercial kitchens and classrooms. It is ADA and lead-free compliant.

Product Information

Standard Information

• Brand: ELKAY
• Manufacturer Part Number: LK940GN04L2H
• Country of Origin: China

Technical Specifications

• Brand: Elkay
• Product Type: Commercial Faucets
• Spread: 8IN
• Number of Handles: 2
• Handle Type: Wrist Blade
• ADA Compliant: Yes
• Finish: Chrome
• Spout Type: Gooseneck
• Material: Brass
• Cartridge Type: Quarter Turn Ceramic Disc
• Length: 3-5/8IN
• Width: 12-3/8IN
• Height: 9-1/5IN
• Faucet Holes: 2
• Spout Reach: 3.63 Inches
• Liters per Minute: 8.33 LPM
• Mounting Location: Wall
• Spout Height: 9.19 Inches
• Gallons per Minute: 2.2 gal/min
• Inlet Connection: 1/2 in
• GPM: 1.5
• Unit_Width: 3.6250
• FinishColor: Polished Chrome
• Finish_Name: Chrome-plated Brass
• Buy_America_Act_Compliant: No
• Commercial_or_Residential: Primarily Commercial
• Valve Type [Specifications]: Quarter Turn Ceramic Disc
• Handle Type [Specifications]: Lever Handle
• Spout Length [Specifications]: 9.1875"
• Body Material [Specifications]: Chrome-Plated Brass
• Mounting Type [Specifications]: Wall Mount
• Number of Holes [Specifications]: 2
• Faucet Operation [Specifications]: Lever Handle
• Residential / Commercial [Specifications]: Commercial
• Mounting Hole Center to Center [Specifications]: 8"
• Country of Origin (subject to change) [Specifications]: China
• Installation Type: Wall mount
• Handle Quantity: 2
• Deck Clearance: 6-5/8"
• Valve Connection: 1/2" NPT Female
• Code Compliance: ASME A112.18.1 CSA B125.1 cUPC NSF 61 NSF 372 CEC Listed IPC
• Note: 1.5 GPM VR aerator installed with 2.2 and .5 GPM inserts included
• Recommended Uses For Product: Kitchen
• Finish Type: Chrome
• Hole Count: 1
• Special Feature: Water Saving System
• Style: Traditional
• Model Name: LK940GN04L2H
• Handle Material: Brass
• Series ID: Centerset
• Warranty Type: limited
• Handle Location: Center
• Spout Design: Gooseneck, 4-inch
• Manufacturer: Elkay
• UPC: 094902393452
• Global Trade Identification Number: 00094902393452
• Product Dimensions: 8"D x 3.63"W x 9.19"H
• Part Number: LK940GN04L2H
• Item model number: LK940GN04L2H
• Is Discontinued By Manufacturer: No
• Item Package Quantity: 1
• Special Features: Water Saving System
• Batteries Included?: No
• Batteries Required?: No
• Warranty Description: 5 year limited warranty
• Spout Style: Gooseneck
• Faucet Centers (in): 8
• Faucet Mount: Splash
• Handle Length (in): 2
• Nozzle Length (in): 4
• Nozzle Type: Gooseneck
• Product: Manual Faucets
• Rating: Better
• Warranty: 1-year Limited Against Defects in Material & Workmanship
• Width (in): 8
• Depth (in): 3.63
• Weight: 6.25
• Product Line: Elkay Commercial
• Introduction Date: 6/3/12
• Low Lead Compliant: Yes
• Mounting: Wall
• Flow Rate (GPM): 1.500 gal/min
• Handles: 2
• Holes: 2
• ASME: Yes
• CEC: Yes
• Unit Of Measure: Each
• Application: Scrub + Handwash
• Contains Batteries: No
• Csa Standards: CSA B125.1
• End Connection 1: 1/2'' NPT Female
• End Connection 2: 1/2'' NPT Female
• Faucet Hole Size: 1.5
• Faucet Hole Spread: 8
• Includes Msds: No
• Lead Law Third Party Certified: Yes
• Lead Leaching Nsf61 Ab100 Applicable Marked: Yes
• Lead Leaching Nsf61 Ab100 Compliant: Yes
• Lead Leaching Nsf61 Ab100 Third Party Certified: Yes
• Npcc: Yes
• Nsf Standard 372: Yes
• Nsf Standard 61: Yes
• Related Item Id: LK940GN08L2H
• Spread In Inches: 8
• Upc Listed: cUPC
• Mpn #: LK940GN04L2H
