Electro Hardware ESO-632-12ZI Hex Standoff 6-32 3/8in 25pk

Product Description

The ELECTRO HARDWARE ESO-632-12ZI is a female hex circuit board standoff designed to create precise spacing between PCBs, panels, and enclosure mounting surfaces. The standoff uses a self-clinching with through-hole fastening method, threading at 6-32 to accept a mating male screw on both the board side and the mating surface. Machined from steel with a zinc-plated finish for corrosion resistance, the hex body profile allows standard wrench engagement during installation. At 0.375 inches overall length with a 0.25-inch width across flats, this standoff is suited for tight-pitch PCB stacking applications where consistent stack height is critical.

This standoff is used in residential and commercial electronic assemblies, control boards, HVAC control panels, electrical enclosures, and industrial PCB mounting applications. The 6-32 thread size is one of the most common thread standards found in North American electronic hardware, making this standoff a frequent replacement or build component in control board fabrication and repair. This listing is sold in a package quantity of 25 pieces, appropriate for production runs or service stock.

Key Features

• 6-32 female thread accepts standard 6-32 male screws on both faces
• Hex body profile at 0.25 inches across flats allows wrench or nut driver engagement
• Self-clinching with through-hole fastening method for secure board mounting
• Zinc-plated steel construction provides corrosion resistance in typical indoor environments
• 0.375 inches overall length provides consistent PCB standoff height
• Package of 25 pieces supports production and service inventory needs

Compatibility

Designed as an OEM-style replacement or new-install component for applications requiring 6-32 threaded female hex standoffs in PCB and panel mounting assemblies.

Installation Notes

Installation is typically performed by electricians, electronics technicians, or HVAC control board service professionals. Power down and de-energize all circuits before servicing any control board or panel assembly. Use a properly sized nut driver or hex wrench matched to the 0.25-inch across-flats dimension to avoid rounding the hex body. Follow applicable NEC guidelines when working inside electrical enclosures or control panels.
