Product Description
Eemax SPEX60 is a compact 6.0 kW tankless point-of-use electric water heater that delivers about 0.7 GPM at a 60 F rise and can activate at low flows down to 0.25 GPM. The unit operates at 277 V and 22 A, incorporates intelligent self-diagnostics, SafeStart dry-fire protection, and an InfoCue LED status indicator. It mounts in any orientation, uses 3/8 in compression connections, and is UL listed and AHRI certified for under-sink applications.
- 6.0 kW, 277 V, 22 A electrical rating; recommended wire 12 AWG and 30 A breaker
- Flow performance: activation 0.25 GPM; 0.7 GPM at 60 F rise; maximum flow 2 GPM
- Omnidirectional mounting, 3/8 in compression water connections, InfoCue LED and SafeStart protection
Product Highlights
Point-of-use 6 kW electric tankless heater for under-sink handwashing and single-fixture applications
Product Information
Standard Information
-
Brand: EEMAX
-
Manufacturer Part Number: SPEX60
-
Country of Origin: United States
Technical Specifications
-
Brand: Eemax
-
MPN: SPEX60
-
Series: FlowCo
-
Type: Tankless water heater (point-of-use)
-
Power: 6.0 kW
-
Wattage: 6000 W
-
Input Voltage: 277 V
-
Phase: Single (1)
-
Frequency: 60 Hz
-
Input Current: 22 A
-
Recommended Wire Size: 12 AWG
-
Recommended Breaker Size: 30 Amps
-
Minimum Activation Flow: 0.25 GPM
-
Rated Flow at 60 F Rise: 0.7 GPM
-
Maximum Flow Rate: 2 GPM
-
Flow Rate at 40 F Rise: 1 GPM
-
Flow Rate at 45 F Rise: 0.9 GPM
-
Flow Rate at 50 F Rise: 0.8 GPM
-
Uniform Energy Factor: 0.96
-
Minimum Water Pressure: 30 PSI
-
Maximum Water Pressure: 150 PSI
-
Water Connection: 3/8 in compression
-
Mounting Type: Omnidirectional (mounts in any orientation)
-
Installation Location: Under sink / point-of-use
-
Dimensions (H x W x D): 10.5 in x 5.25 in x 3 in
-
Weight: 3 lbs
-
Housing Material: Thermoplastic / ABS
-
Heating Element Material: Nichrome / nickel chrome (replaceable cartridge)
-
Temperature Range: 70 F to 140 F output range (factory cut-off documented at 150 F)
-
Applications: Handwashing, lavatory faucets, metering faucets, sensor faucets, under-sink fixtures
-
Certifications: UL listed; AHRI certified; ANSI/NSF 372 lead-free compliant; cETLus listed (per sources)
-
Replacement Parts: EX1280 (element), EX383 (board) and others listed by manufacturer
-
Country of Origin: United States (assembled in USA / Made in USA per sources)
