Edwards Signaling FX-5R Conventional Fire Alarm Control Panel, 5 Zone, 120V, Red

Product Description

The Edwards Signaling FX-5R is a conventional fire alarm control panel designed for effective fire detection and alerting. This model features five Class B initiating device circuits (IDCs) and two Class B notification appliance circuits (NACs). The control panel operates at 120VAC and has a NAC power output of 3.5A, ensuring reliable performance.

• Five Class B IDCs for versatile fire detection.
• Integrated DACT for efficient communication.
• Supports Class A operation for enhanced circuit reliability.

Product Highlights

This fire alarm control panel is suitable for both new installations and retrofits. It allows for easy operation and installation with front panel programming capabilities and walk test options.

Product Information

Standard Information

• Brand: Edwards Signaling
• MPN: FX-5R

Technical Specifications

• Power Supply: 120VAC
• Output Voltage: 24VDC
• NAC Power: 3.5A
• IDCs: 5 Class B
• NACs: 2 Class B
• Operating Temperature: 42 - 120°F
• Operating Humidity: 93%
• Certifications: UL, ULC, CSFM
