Edwards Signaling 48XBRMR24D Led Warning Light 24VDC

Product Description

The EDWARDS SIGNALING 48XBRMR24D is a dual-mode LED warning light that operates in both flashing and steady modes, designed for industrial and commercial signaling applications. It runs on 24 volts DC, draws 0.22 amps, and produces a red lens output at 65 flashes per minute in flash mode. The unit is rated NEMA 4X, making it suitable for wet, corrosive, and washdown environments. Licensed electricians and facility maintenance technicians install this type of device as part of alarm, process, or status indicator systems. The housing is impact-resistant, shatter-resistant, vibration-resistant, and weatherproof.

This light is used in both indoor and outdoor installations where a highly visible panel or pipe-mounted indicator is required. Typical applications include machine status panels, alarm annunciator boards, process control equipment, and facility alert systems in commercial, industrial, and light manufacturing environments. It mounts to a panel surface or to a 1/2-inch pipe or pendant fitting, giving installers flexibility in positioning. The NEMA 4X rating makes it appropriate for food processing, chemical handling, and outdoor enclosure installations where moisture and corrosion resistance are required.

Key Features

• Dual-mode operation: selectable flashing and steady output in a single unit
• LED lamp type for long service life and low current draw (0.22 amps at 24 volts DC)
• 65 flashes per minute output in flash mode
• NEMA 4X rated: weatherproof, impact-resistant, shatter-resistant, and vibration-resistant
• Panel mount and 1/2-inch pipe mount options provide flexible installation configurations
• Wide operating temperature range: -31 degrees F to 150.80 degrees F
• cULus Listed and UL Listed

Compatibility

Designed as an OEM-style panel or pipe-mount LED warning light for 24-volt DC signaling circuits in industrial control, alarm, and process indicator applications.

Installation Notes

Installation is typically performed by a licensed electrician in accordance with NEC requirements for signaling and indicator circuits. Disconnect and lock out all power to the circuit before wiring or mounting. For pipe mount installations, verify that the mounting pipe or pendant fitting is 1/2 inch and properly supported. Confirm supply voltage is 24 volts DC before energizing the unit.
