Edwards 590 Class 2 Low Voltage Signaling Transformer 5 VA

Product Description

The Edwards 590 Series Class 2 Signaling Transformers are easy to install, low voltage power sources for residential, commercial, and industrial uses. These transformers mount in a standard 1/2 in knockout or surface mounts using the provided foot mounts and are suitable for mounting in both plastic and metal back boxes.

• Non-regenerative thermal overload protection
• Grounding wire
• Pre-stripped primary side pigtails

Product Highlights

Ideal for standard doorbells and chimes in residential and commercial applications. Features screw terminal connections on secondary.

Product Information

Standard Information

• Brand: EDWARDS
• Manufacturer Part Number: 590
• Country of Origin: China

Technical Specifications

• Frequency Rating: 50/60 Hz
• Mounting Type: Surface
• Power Rating: 5 VA
• Primary Voltage: 120 VAC
• Standard & Approvals: CSA Certified, UL Listed
• Application: For Residential, Commercial and Industrial Applications
• Type: Low Voltage Class 2
• Series: 590
• Secondary Voltage: 10 VAC
• Manufacturer Part Number: 590
• Brand Name: Edwards Signaling
• Manufacturer: UTC Fire & Security Company
• Product Name: Step Down Transformer
• Product Series: 590
• Product Type: Open Frame
• Output Receptacle Type: Screw Terminal
• Input Voltage: 120V AC
• Compatibility: Doorbells and Chimes
