Edwards 435-4E1 Vibrating Bell 12V DC 4 in

Product Description

The EDWARDS 435-4E1 series are vibrating bells that produce a long, continuous ringing sound. The striker continues to strike the gong in rapid-fire as long as current is applied. It can be mounted directly on a surface. The universal adaptaplate fits any single gang box. It is UL Listed and PLC compatible.

• Universal Adaptaplate mounts directly on surface or electrical box
• Weatherproof by adding 449 back box
• 4", 6", 8" and 10" Gong sizes

Product Highlights

The Edwards 435 series vibrating bell is ideal for timing, scheduling, and general alarm applications. It has a corrosion-resistant heat flowed epoxy finish.

Product Information

Standard Information

• Brand: EDWARDS
• Manufacturer Part Number: 435-4E1
• Country of Origin: Mexico

Technical Specifications

• Brand Name: Edwards Signaling
• Manufacturer Part Number: 435-4E1
• Product Series: 435
• Product Type: Bell
• Voltage Rating: 12 VDC
• Amperage Rating: 0.125 A
• Power Rating: 1.5 VA
• Sound Level: 100/90 dB
• Mounting Type: Surface
• Specifications Met: UL Listed
• Gong Size: 4 in
• Color: Gray
• Material: Die Cast
• Operating Voltage: 12V
• Operating Current: 0.125A
• For Location: Indoor; Outdoor
• Sound Principle: Vibrating
• Features: Specified for Timing, Scheduling, and General Alarm Applications
• Sound Continuity: Continuous
• Vibration: Vibrating
• Standards: FM; UL
• Alarm Volume @ 1 m - Maximum: 100 dB
• Alarm Volume @ 10 ft - Maximum: 90 dB
• Number of Sound Patterns: 1
• Type: Sirens & Alarms
• Model: 435-4E1
• Description: 4 In Vibrating Bell 12V Dc
• Voltage: 12 VDC
• Nominal Voltage: 12 VDC
• Size: 4 "
• Current Rating: 0.125 A
• Approvals: UL
