Edwards 340-10G5 Signaling 10 Inch Vibrating Bell 24V

Product Description

The Edwards Signaling 340-10G5 is a 10-inch AC vibrating bell suitable for timing, scheduling, paging, and general alarm applications. It produces a long, continuous ringing sound with a striker that rapidly hits the gong when current is applied. It can be used outdoors with an approved box.

• Can be used in outdoor applications with the addition of an approved box for the application
• Produces a long, continuous ringing sound
• Striker continues to strike the gong in rapid-fire as long as current is applied

Product Highlights

The Edwards 340-10G5 is ideal for timing, scheduling, paging and general alarm applications.

Product Information

Standard Information

• Brand: EDWARDS
• Manufacturer Part Number: 340-10G5
• Country of Origin: US

Technical Specifications

• Amperage Rating: 0.35
• Application: Timing, Scheduling, Paging, etc.
• Brand Name: Edwards Signaling
• Current_Type: AC
• Frequency_Rating: 60
• Housing_Color: Gray
• Housing_Material: Die cast
• Loudness: 106/96
• Material: Die Cast
• Special Features: Completely assembled with all hardware supplied Corrosion-resistant heat flowed epoxy finish Mounts directly on surface or electrical box Self-compensating solenoid plunger
• Standard: UL Listed, FM Approved
• Sub_Brand: Edwards
• Type: Vibrating
• Voltage Rating: 24
• Style: Classic
• Current Rating: 0.35 A
• Impedance: 30 ohm
• Mounting Type: Surface Mount
• Operating Voltage Range: 24 V
• Power Rating: 8.4 VA
• Primary Type: Bell
• Series: 340 Series
• Size: 10 In.
• Sound Level: 106 dB
• Decibels: 106 dB
• Operating Voltage: 24 V AC
• Product Family: 340 Series
• Product Type: Audible Signals
• Product Category: Safety Equipment
• CUSTOM_Product Type2: Bells
• Product Line: Adaptabel
• Product Name: 340 Series Adaptabel AC Vibrating Bells
• Product Series: 340
• Security Alarm: Audible
• Sound Emission: 106 dB
• Durability: Corrosion Resistant, Dustproof, Shockproof, Weatherproof
• Form Factor: Surface Mount
• Input Voltage: 24V AC
• Diameter: 10"
• UNSPSC: 60131402
