EDWARD W. DANIEL 14631 Shoulder Eye Bolt #3/8-16 x 3-1/4 1030 Forged Carbon Steel

Product Description

The Edward W. Daniel 14631 Shoulder Eye Bolt is constructed from 1030 forged carbon steel and is part of the SEB-14 series. This shoulder eye bolt has a size of #3/8-16 and a length of three and a quarter inches. It is designed for use in a variety of applications where secure lifting points are required.

• Meets ASTM-A489 and ANSI B-18.15-1969 standards
• Heat treated for enhanced strength and toughness
• Self-colored with a smooth finish

Product Highlights

This shoulder eye bolt is ideal for direct drive ventilation units, ensuring secure attachment points in various equipment.

Product Information

Standard Information

• Brand: Edward W. Daniel
• Item Name: Shoulder Eye Bolt

Technical Specifications

• Size: #3/8-16 x 3.25 inches
• Material: 1030 Forged Carbon Steel
• Series: SEB-14
• Net Weight: 0.190 lb
• Inner Diameter: 1 inch
• Outer Diameter: 1-11/16 inches
• Center of Eye to Shoulder: 1-1/8 inches
