Edward W. Daniel 14008M Metric Shoulder Eye Bolt, M8 x 67.5, 1030 Forged Carbon Steel, Self-Colored

Product Description

The Edward W. Daniel 14008M Metric Shoulder Eye Bolt is made from 1030 forged carbon steel. This robust shoulder eye bolt measures M8 x 67.5 millimeters, making it suitable for various applications.

• Constructed from high-quality 1030 forged carbon steel.
• Heat-treated for enhanced strength and toughness.
• Features ISO coarse thread-6G for secure fastening.

Product Highlights

This shoulder eye bolt is ideal for direct drive ventilation units and other applications where secure lifting is required. Ensure proper seating against the mating surface for full rated capacity.

Product Information

Standard Information

• Brand: Edward W. Daniel
• Part Number: EYEBOLTM8

Technical Specifications

• Type: Metric
• Size: M8 x 67.5
• Material: 1030 Forged Carbon Steel
• Inner Diameter: 25 mm
• Outer Diameter: 43 mm
• Center of Eye to Shoulder: 27.80 mm
• Tensile Strength: 65000 psi minimum
• Net Weight: 0.17 lb
