Edison NDN3-WH 3-Pole Terminal Block 600 VAC 30 Amp 22 to 10 AWG

Product Description

The Edison NDN3-WH is a three-pole terminal block for electrical connections. It supports a voltage rating of 600 VAC and can handle up to thirty amps. This product accommodates wire sizes from twenty-two to ten AWG. It is designed for quick and simple installation on C-Rail or DIN rail. Constructed with thermoplastic insulation and equipped with zinc-plated screws, it ensures durability.

• Three-pole configuration
• Suitable for C-Rail and DIN Rail mounting
• Wire size compatibility: twenty-two to ten AWG

Product Highlights

This terminal block provides reliable and efficient electrical connections. It can be quickly mounted on standard rails, making it ideal for various electrical applications.

Product Information

Standard Information

• Brand: Edison
• MPN: NDN3-WH

Technical Specifications

• Voltage Rating: 600 VAC
• Amperage Rating: 30 A
• Number of Poles: 3
• Wire Size: 22 to 10 AWG
• Mounting Type: C Rail/DIN Rail
• Terminal Type: Feed-Through
• Connection Type: Screw
• Screw Size: #6-32 TPI
• Spacing: 7.62 mm
• Torque Rating: 18 in-lb
• Operating Temperature: 105 deg C
• Material: Thermoplastic
• Color: White
• Dimensions: 33.3 mm H x 23.9 mm W x 42.4 mm D
• Product Weight: 0.5 LB
