ECM Industries VRBR-14-10-P50 ILSCO CU CMP 16-14 #10 VYL-INS UL RING

Product Description

ECM Industries VRBR-14-10-P50 is a Type VRBR Insulated Standard ring terminal made for copper conductors. It is designed for use with 16 to 14 AWG wire and features a #10 stud for easy attachment. The terminal has a length of zero point eight five eight inches and a ring tongue width of zero point three three five inches, ensuring a secure fit.

• For use with 16 to 14 AWG copper wire
• Features a brazed barrel for enhanced conductivity
• UL approved for safety and reliability

Product Highlights

Reliable copper conductivity and easy wire range identification for effective installation

Product Information

Standard Information

• Brand: ECM Industries
• Manufacturer Part Number: VRBR-14-10-P50

Technical Specifications

• Conductor Size: 16 to 14 AWG
• Stud Size: #10
• Voltage Rating: 600 VAC
• Temperature Rating: 105 deg C
• Material: Copper Alloy
• Dimensions: 2.88 in H x 1.21 in W x 3.5 in D
• Tongue Type: Ring
• Finish: Electro-Tin Plated
