ECM Industries PBTS-3-350-F ILSCO INS(3) 350-6 250FX 4/0M 262DLO T UL CSA

Product Description

ECM Industries PBTS-3-350-F is a flexible multi-tap connector designed for various electrical applications. This connector is engineered for use with aluminum and copper conductors, rated up to 600 VAC. It can accommodate wire sizes from 6 AWG to 350 kcmil. Its compact dimensions are three point five six inches long, two point zero three inches wide, and two point six two inches high.

• Type PBTF 1-sided entry with three ports
• Rated for 350 Amps
• Temperature range from -45 to 90 degrees Celsius

Product Highlights

The PBTS-3-350-F connector improves flexibility and reliability in the field. It features patented screw technology that eliminates the need for wire sleeves, making it easy to use without compromising performance.

Product Information

Standard Information

• Manufacturer: ECM Industries
• UPC: 78366971248

Technical Specifications

• Conductor Type: Aluminum/Copper
• Dimensions: 3.56 in L x 2.03 in W x 2.62 in H
• Manufacturer Part Number: PBTS-3-350-F
• Material: Aluminum
• Specifications: 6 AWG to 350 kcmil Wire, 5/16 in Hex, 350 A
• Standards/Approvals: CSA File No. LR-29601, UL File No. E6207/453G/486A/B
• Temperature Rating: -45 to 90 deg C
• Voltage Rating: 600 VAC
