ECM Industries CT-6 ILSCO CU CMP 6 T UL

Product Description

ECM Industries CT-6 is a SureCrimp compression sleeve designed for use with copper conductors. This short barrel compression sleeve is suitable for 6 AWG conductors. It features a die code of I-24 and a length of one and three-fourth inches. The product is rated for 600 VAC and has a temperature rating of 90 degrees Celsius. It provides reliable performance and ensures a secure electrical connection.

• Designed for 6 AWG copper conductors
• Crimp connector with a rating of 600 VAC
• Manufactured from high strength seamless copper tubing

Product Highlights

The CT-6 ensures maximum cable insertion and reduces inventory requirements. It is suitable for grounding and bonding applications.

Product Information

Standard Information

• Manufacturer: ECM Industries
• UPC: 78366911590

Technical Specifications

• Application: For use with splicer/reducer, grounding and bonding applications
• Color: Blue
• Conductor Size: 6 AWG
• Conductor Type: Copper
• Connector Type: Crimp
• Die Code: I-24
• Dimensions: 0.225 in ID x 0.312 in OD
• Finish: Electro-Plated Tin
• Length: 1-3/4 in
• Material: Copper
• Series: CT Series
• Standards/Approvals: CSA File No. LR29601 | NEBS Level 3 | UL 486A-BI | UL 467 File No. E6207
• Temperature Rating: 90 degrees Celsius
• Type: Short Barrel
• Voltage Rating: 600 VAC
