ECM Industries CT-250 CT-250 ILSCO CU CMP 250 T UL

Product Description

ECM Industries CT-250 is a SureCrimp Compression Sleeve designed for 250 kcmil copper conductors. This short barrel compression connector offers a secure and reliable connection. The product is manufactured from high-strength seamless copper tubing with electro-tin plating, ensuring durability and low contact resistance.

• For use with copper conductors.
• Designed for crimping applications.
• Rated for up to 600 VAC, with a temperature rating of 90 degrees Celsius.

Product Highlights

This compression sleeve is compatible with various ILSCO tools and provides excellent crimping characteristics and versatility.

Product Information

Standard Information

• Manufacturer: ECM Industries
• Manufacturer Part Number: CT-250

Technical Specifications

• Application: For use with splicer/reducer, grounding, and bonding applications
• Color: Yellow
• Conductor Size: 250 kcmil
• Conductor Type: Copper
• Connector Type: Crimp
• Die Code: I-62
• Dimensions: 0.593 in ID x 0.75 in OD
• Finish: Electro-Plated Tin
• Length: 2-1/4 in
• Material: Copper
• Series: CT Series
• Specifications: 1-3/16 in L Stripe
• Standards/Approvals: CSA File No. LR29601, NEBS Level 3, UL 486A-BI, UL 453G, UL 467 File No. E6207
• Temperature Rating: 90 deg C
• Voltage Rating: 600 VAC
