ECM Industries CT-1 ILSCO CU CMP 1 T UL

Product Description

The ECM Industries CT-1 is an ILSCO SureCrimp Compression Sleeve designed for reliable electrical connections. This product uses high-strength copper for optimal conductivity and crimping characteristics.

• For use with splicer/reducer, grounding, and bonding applications.
• Rated for 600 VAC and 90 degrees Celsius.
• Compatible with various ILSCO tools for effective use.

Product Highlights

This compression sleeve is ideal for electrical repairs and installations, providing low contact resistance and easy conductor insertion.

Product Information

Standard Information

• Manufacturer: ECM Industries
• Manufacturer Part Number: CT-1

Technical Specifications

• Application: For use with splicer/reducer, grounding and bonding applications
• Color: Green
• Conductor Size: 1 AWG
• Conductor Type: Copper
• Connector Type: Crimp
• Die Code: I-37
• Dimensions: 0.359 in ID x 0.468 in OD
• Finish: Electro-Plated Tin
• Length: 1-7/8 in
• Material: Copper
• Series: CT Series
• Voltage Rating: 600 VAC
• Temperature Rating: 90 degrees Celsius
• Standards/Approvals: CSA File No. LR29601 | NEBS Level 3 | UL 486A-BIUL 453G | UL 467 File No. E6207 | ECCN EAR99 | PROP65: Cancer -www.p65warnings.ca.gov
