ECM Industries CSBS-14-P50 ILSCO 16-14 Cool Seal Butt Splice

Product Description

ECM Industries CSBS-14-P50 is a Cool Seal Butt Splice designed for insulated sealed applications. It accommodates copper conductors ranging from sixteen to fourteen AWG. This splice measures one point zero thirty-one inches in length and features a seamless barrel. It operates at a voltage rating of six hundred VAC and a temperature rating of one hundred five degrees Celsius.

• Suitable for various wire sizes from 16 to 14 AWG.
• Fast and easy installation with strip and crimp feature.
• Environmentally sealed connection that does not require heat.

Product Highlights

Provides maximum conductivity and reliable connections. The splice features nylon insulation and an innovative anaerobic encapsulated sealant to lock out moisture and air.

Product Information

Standard Information

• Manufacturer: ECM Industries
• UPC: 78366920340

Technical Specifications

• Color: Blue
• Conductor Size: 16 to 14 AWG
• Conductor Type: Copper
• Length: 1.031 inches
• Manufacturer Part Number: CSBS-14-P50
• Material: Copper Alloy
• Voltage Rating: 600 VAC
• Temperature Rating: 105 degrees Celsius
• Standards/Approvals: UL 486C/453G/File No. E6207 | PROP65: cancer and reproductive harm - www.P65Warnings.ca.gov
