ECM Industries CLND-250-12-134 ILSCO CU CMP 250 KCMIL 9/16-1-3/4 TUL CSA 78366964166

Product Description

ECM Industries CLND-250-12-134 is a lug compression connector designed for electrical applications. This product is part of the ILSCO SureCrimp series and accommodates flex copper conductors ranging from 1/0 AWG to 250 kcmil. It features a die code of ILD-62 and can handle voltages up to thirty-five kilovolts (kV) with a temperature rating of ninety degrees Celsius.

• Application: Terminating connector suitable for grounding and bonding.
• Material: Made from tin plated copper for optimal conductivity.
• Dimensions: Overall length of five point two one nine inches with a barrel size of zero point five nine three inches ID.

Product Highlights

This connector is reliable for high voltage applications and provides excellent crimping characteristics. It effectively reduces contact resistance, ensuring efficient conductor insertion.

Product Information

Standard Information

• Manufacturer: ECM Industries
• UPC: 78366964166

Technical Specifications

• Application: Terminating Connector, Grounding and Bonding Applications
• Barrel Size: 0.593 in ID x 0.75 in OD x 1.688 in L
• Color: Yellow
• Conductor Size: 1/0 AWG to 250 kcmil
• Material: Tin Plated Copper
• Overall Length: 5.219 in
• Voltage Rating: 600 VAC to 35 kV VAC
• Temperature Rating: 90 °C
