ECM Industries ASN-3/0 ILSCO AL CMP SLV 3/0 AWG T

Product Description

ECM Industries ASN-3/0 is a compression sleeve designed for use with aluminum and copper conductors. This product supports conductor sizes from one to three/zero AWG. The compression sleeve measures two point seventy-one inches in length and is suited for high voltage applications.

• Designed for 1 to 3/0 AWG aluminum or copper conductors
• Constructed from high strength aluminum alloy
• Electro-Plated Tin finish for low contact resistance

Product Highlights

This dual-rated compression sleeve is suitable for splicing and reducing connections.

Product Information

Standard Information

• Manufacturer: ECM Industries
• UPC: 78366918478

Technical Specifications

• Application: For use with splicer and reducer
• Color: Olive
• Conductor Size: 1 to 3/0 AWG
• Conductor Type: Aluminum/Copper
• Connector Type: Crimp
• Die Code: 297
• Dimensions: 0.495 in ID x 0.761 in OD
• Finish: Electro-Plated Tin
• Length: 2.71 in
• Material: Aluminum Alloy
• Temperature Rating: 90 deg C
• Standards/Approvals: UL 486A-B|UL 453G File No. E6207|CSA File No. LR29601|ECCN EAR99
