ECM Industries ALND-700/750-12-134 ILSCO AL COMP 700/750 KCMIL 9/16-1-3/4 T UL CS

Product Description

ECM Industries ALND-700/750-12-134 is a compression connector lug designed for aluminum and copper conductors. This connector is suitable for conductors sized from seven hundred to seven hundred fifty kcmil. The product features a narrow tongue for limited space applications and a long barrel to ensure a secure and reliable connection.

• Manufactured from high strength aluminum alloy for maximum conductivity.
• Electro tin plated to reduce contact resistance.
• Color-coded end cap for easy identification of the proper compression die.

Product Highlights

This connector provides excellent crimping characteristics and is pre-filled with De-ox to prevent oxide formation. It is also dual rated for aluminum and copper, making it versatile for various electrical applications.

Product Information

Standard Information

• Manufacturer: ECM Industries
• Series: ALND

Technical Specifications

• Application: For terminating connector
• Barrel Size: 1.03 inches ID x 1.46 inches OD x 2.964 inches L
• Conductor Size: 700/750 kcmil
• Material: Aluminum
• Overall Length: 7.195 inches
• Voltage Rating: 600 VAC
• Temperature Rating: 90 degrees C
• Standards/Approvals: UL 486A/B, CSA
