ECM Industries ALND-400-12-134 ILSCO AL COMP 400 KCMIL 9/16-1-3/4 T UL CSA

Product Description

ECM Industries ALND-400-12-134 is a compression connector lug designed for aluminum and copper conductors from four aught AWG to four hundred kcmil. This product features a narrow tongue and is suitable for high-voltage applications when proper insulation techniques are employed. It's important for electrical wiring applications.

• 2-hole compression connector made of high-strength aluminum alloy
• Compatible with both aluminum and copper conductors
• Electro tin plated for low contact resistance

Product Highlights

Engineered for reliable electrical connections, this compression connector provides strong conductivity and is ideal for tight spaces.

Product Information

Standard Information

• Manufacturer: ECM Industries
• MPN: ALND-400-12-134

Technical Specifications

• Application: For terminating connector
• Barrel Size: 0.762 inches ID x 1.188 inches OD x 2.303 inches length
• Color: Green
• Conductor Size: 4/0 AWG to 400 kcmil
• Conductor Type: Aluminum/Copper
• Die Code: 472
• Material: Aluminum
• Mounting Hole Size: 9/16 inches diameter
• Overall Length: 5.99 inches
• Series: ALND
• Specifications: 2.3655 inches length strip, 1-3/4 inches mounting hole spacing, Electro Tin Plated Finish
• Standards/Approvals: UL 486A/B File No. E6207, UL 453G File No. E6207, CSA File No. LR29601, ECCN EAR99
• Stud Size: 1/2 inches
• Temperature Rating: 90 degrees Celsius
• Tongue Size: 3 inches length x 1.623 inches width x 0.426 inches thickness
• Tongue Type: Narrow
• Type: 2-Hole
• Voltage Rating: 600 VAC
