ECM Industries AK-1/0 ILSCO AL MEC (R) 1/0-8 (T) 1/0-8 T ULCSA

Product Description

ECM Industries AK-1/0 is a dual-rated split bolt connector suitable for aluminum conductors. It supports solid and stranded connections from two to one-aught American Wire Gauge (AWG). The connector is designed for circuits rated at thirty-five kilovolts or less. Its compact design simplifies installation.

• Rated for solid and stranded aluminum conductors of 2 to 1/0 AWG and 8 to 1/0 AWG
• Features a bolt size of 0.75 x 1.92 inches
• Voltage rating of 2000 VAC for reliable performance

Product Highlights

This connector offers application versatility, providing low contact resistance and preventing galvanic corrosion between dissimilar metals.

Product Information

Standard Information

• Manufacturer: ECM Industries
• UPC: 78366900833

Technical Specifications

• Application: For circuits rated 35 kV or less, tap and splice connector
• Conductor Size: 2 to 1/0 AWG, 8 to 1/0 AWG
• Conductor Type: Solid/Stranded Aluminum
• Dimensions: 1.92 inches H x 1 inch W
• Finish: Electro-Plated Tin
• Material: Aluminum Alloy
• Temperature Rating: 90 degrees C
• Voltage Rating: 2000 VAC
• Manufacturer Part Number: AK-1/0
