Eclipse 833NF Alnico Pot Magnet 9 Lb Threaded Hole

Product Description

The ECLIPSE 833NF is a red-bodied Alnico pot magnet designed for secure threaded mounting in industrial, HVAC, and mechanical service applications. Built from Grade 5 Alnico encased in mild steel, this pot magnet delivers an average pull force of 9 pounds and a maximum pull force of 13.4 pounds. The 10-32 threaded hole mount allows direct fastening to panels, brackets, or fixtures without adhesives. Rated to a maximum operating temperature of 428 degrees F, the 833NF is well suited for environments where standard ferrite or neodymium magnets would lose performance. Licensed HVAC technicians, electricians, and mechanical contractors commonly use pot magnets of this type for sensor positioning, door latching, and fixture retention.

The ECLIPSE 833NF fits residential and light commercial applications where a compact, high-temperature-rated magnet is required. Its 1-1/16 inch diameter and 1 inch height make it easy to install in tight spaces. The 10-32 threaded hole accepts standard hardware for direct attachment to metal surfaces, equipment enclosures, and structural members. The red mild steel shell concentrates flux toward the working face, maximizing holding force at the contact point.

Key Features

• Average pull force of 9 pounds; maximum pull force of 13.4 pounds
• Grade 5 Alnico magnet material for stable output at elevated temperatures
• Maximum operating temperature of 428 degrees F, suitable for high-heat service environments
• 10-32 threaded hole mount for direct fastener attachment
• Mild steel shell concentrates magnetic flux at the working face
• Compact form factor: 1-1/16 inch diameter, 1 inch height

Compatibility

Designed as a standard threaded pot magnet for use in industrial, HVAC, electrical, and mechanical applications requiring a 10-32 threaded hole mount and Grade 5 Alnico magnetic material.

Installation Notes

Installation is performed by threading a compatible 10-32 fastener through the host bracket or panel into the magnet body. Ensure the mating surface is clean, flat, and free of debris to achieve rated pull force. Do not exceed the rated maximum operating temperature of 428 degrees F. No special tools are required beyond standard hand tools appropriate for 10-32 hardware.
