Eaton Z-SV/UL-16/3P-3TE/6 CH FAZ-NA UL 489 80A 3-P MCB Bus Bar for 2 Breakers

Product Description

The EATON Z-SV/UL-16/3P-3TE/6 is a FAZ-NA type 3-phase/pole busbar designed for circuit protection applications. It is suitable for use with FAZ-NA, FAZ-RT DIN Rail Miniature, residual current, and combined residual current/power circuit breakers. The busbar features 3-phase, 3-pole, 80 A, 690 VAC, and 6-terminal specifications.

• Suitable for use with FAZ-NA, FAZ-RT DIN Rail Miniature, Residual Current, Combined Residual Current/Power Circuit Breaker
• 3-Phase, 3-Pole, 80 A, 690 VAC, 6-Terminal
• Dimensions: 0.61 in L x 3.9 in W x 1.81 in H

Product Highlights

EATON's Z-SV/UL-16/3P-3TE/6 busbar is designed for circuit protection and compatible with multiple breaker types. It supports 3-phase, 3-pole configurations up to 80A.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: Z-SV/UL-16/3P-3TE/6

Technical Specifications

• Manufacturer Part Number: Z-SV/UL-16/3P-3TE/6
• Type: Type FAZ-NA 3-Phase/Pole
• Suitable For Use With: FAZ-NA, FAZ-RT DIN Rail Miniature, Residual Current, Combined Residual Current/Power Circuit Breaker
• Specifications: 3-Phase, 3-Pole, 80 A, 690 VAC, 6-Terminal
• Standards/Approvals: UL 489 File No. E257181|IEC/EN 60898|CE Certified
• Application: Circuit Protection Applications
