Eaton Z-SV/UL-16/2P-2TE/18 Bus Bar

Product Description

The EATON Z-SV/UL-16/2P-2TE/18 is a bus bar designed for use in electrical distribution and terminal block assemblies. Bus bars serve as a common conductor point, allowing multiple circuits or terminals to share a single connection point within a panel or enclosure. This component is installed by licensed electricians working on panel builds, control cabinets, and industrial distribution systems where organized, low-resistance connections are required.

This bus bar is suited for use in commercial and industrial electrical enclosures, terminal block systems, and distribution panels. It is typically installed during panel assembly or retrofit work where a reliable common connection point is needed across multiple terminal positions. Electricians and panel builders use this type of component when consolidating circuit connections in a compact, organized format.

Key Features

• Common conductor design supports multiple terminal connections from a single bus point
• 2-pole configuration for dual-circuit distribution applications
• UL-recognized construction suitable for use in listed electrical assemblies
• Compact form factor fits standard terminal block and enclosure mounting arrangements

Compatibility

Designed as an OEM-style component for use with EATON terminal block systems and compatible electrical distribution enclosures requiring a 2-pole bus bar configuration.

Installation Notes

Installation should be performed by a licensed electrician in accordance with applicable NEC requirements. De-energize and lock out the panel or enclosure before installing or servicing the bus bar. Verify that the bus bar seating is secure within the terminal block track before restoring power. Do not exceed the rated current or voltage limits for the assembly.

Technical Specifications

• Poles: 2
• UPC: 01508104707

Standard Information

• Brand: EATON
• Manufacturer Part Number: Z-SV/UL-16/2P-2TE/18
