Eaton XTRE10B40A Ac Operated Timing Relay

Product Description

The EATON XTRE10B40A is an AC operated timing relay designed for use in industrial and commercial electrical control systems. Timing relays provide timed switching functions that sequence or delay electrical loads within a control circuit. The XTRE10B40A operates on AC voltage and delivers reliable timed output switching for panel-mounted control applications. At 0.5 pounds and compact dimensions of 3.5 inches by 4 inches by 2 inches, the unit fits efficiently into standard control enclosures and DIN-rail or panel configurations.

This timing relay is suited for commercial and light industrial control panel applications where timed relay logic is required. Typical install scenarios include motor control centers, HVAC control panels, and automated sequencing circuits where a delayed or timed switching action is needed. Licensed electricians and controls technicians are the primary installers of this device in new construction and retrofit control panel work.

Key Features

• AC operated input for compatibility with standard control circuit voltages
• Compact footprint at 3.5 x 4 x 2 inches for panel or enclosure mounting
• Lightweight construction at 0.5 pounds for easy handling during panel assembly
• Timed switching output for sequencing or delay control logic

Compatibility

Designed as an OEM-style replacement or direct-fit timing relay for AC-powered industrial and commercial electrical control panels requiring timed switching functions.

Installation Notes

Installation should be performed by a licensed electrician in accordance with NEC guidelines and applicable local codes. De-energize and lock out the control panel before removing or installing any timing relay. Verify that the supply voltage and timing range match the circuit requirements before wiring. Do not exceed the relay contact ratings when connecting load circuits.

Technical Specifications

• Operation Type: AC Operated
• Length: 3.5 inches
• Width: 4 inches
• Height: 2 inches
• Weight: 0.5 pounds
• UPC: 01508276326

Standard Information

• Brand: EATON
• Manufacturer Part Number: XTRE10B40A
