Eaton XTPR2P5BC1 Manual Motor Protector 1.6 to 2.5 Amp

Product Description

The Eaton XTPR2P5BC1 is a manual motor protector designed for electrical control applications. This model supports a current range from 1.6 to 2.5 amps. It features a rotary type control and is built to enhance the safety of electrical machinery. Ideal for integration in electrical assemblies and panels, it ensures optimal performance and protection.

• Supports up to 2.5 amps of current
• Rotary type control for easy operation
• Class 10 thermal overload protection

Product Highlights

The Eaton XTPR2P5BC1 is part of the XT series, ensuring high-quality motor protection. It is suitable for diverse applications in industrial settings, particularly in electrical assemblies and panels.

Product Information

Standard Information

• Manufacturer: Eaton
• Model No: XTPR2P5BC1

Technical Specifications

• Amperage: 2.5 A
• Voltage Rating: 690 VAC
• Frequency: 40 to 60 Hz
• Size: 45 mm
• Dimensions: 4 inches L x 2 inches H
• Weight: 0.4 lb
• Overload Relay: Bi-Metal
• Application: Electrical assemblies, panels, and EOEMs
