Eaton XTCEC018C10TD XT IEC Contactor 18A 24-27 Vdc 1NO

Product Description

The Eaton XTCEC018C10TD is an XT IEC contactor designed to handle 18 Amperes at coil voltages between 24 to 27 VDC. This three-pole, non-reversing contactor is ideal for electrical assemblies, panels, and OEM applications. It is compatible with a range of electronic overload relays and bimetal relays. The device supports high efficiency due to lower power consumption, resulting in reduced size and cost for power supply units.

• Rated for 18A and operates with specified coil voltage of 24-27 VDC.
• Features a spring cage terminal for easy and secure wiring connections.
• Operates efficiently over a wide temperature range from -25 to 60 degrees Celsius.

Product Highlights

The XT IEC contactors are versatile devices suitable for global use, covering mini contactor relays up to seven Amperes to vacuum contactors up to 3180 Amperes.

Product Information

Standard Information

• Catalog Number: XTCEC018C10TD
• Manufacturer: Eaton

Technical Specifications

• Coil Voltage: 24-27 VDC
• Contact Configuration: 1 NO
• Number of Poles: 3
• Operating Temperature: -25 to 60 degrees Celsius
• Type: Full Voltage Non-Reversing
• Contact Rating: 18 A
• Series: XT Series
• Terminal Type: Spring Cage
