Eaton XTCE025C10TD Full Voltage Non-Reversing IEC Contactor 25A 24-27 VDC 1NO

Product Description

Eaton offers the XTCE025C10TD Full Voltage Non-Reversing IEC Contactor. This unit operates at twenty-five amperes and has a coil voltage of twenty-four to twenty-seven VDC. The XT series provides reliable control for various electrical assemblies and panels.

• Three-pole configuration for versatile use
• Designed for 24 to 27 VDC applications
• Compatible with DIN rail or panel mounting

Product Highlights

This Eaton contactor is suitable for controlling motors and power equipment. Ideal for electrical assembly applications, it combines efficiency with compact size.

Product Information

Standard Information

• Catalog Number: XTCE025C10TD
• Manufacturer: Eaton

Technical Specifications

• Amperage: 25 Amp
• Coil Voltage: 24-27 VDC
• Number of Poles: 3
• Contact Configuration: 1 NO
• Frame Size: 45 mm
• Weight: 1.2 lb
• Operating Temperature: -13 to 122 degrees F
• Standards: CSA Certified, UL Listed, EN 60947, IEC 60947, RoHS Compliant, CE Marked
