Eaton XTCE012B10TD Eaton XT IEC Contactor 24 VDC 12A Frame B

Product Description

The Eaton XTCE012B10TD is an IEC contactor designed for reliable control in electrical assemblies. This full voltage non-reversing contactor operates at twelve amperes with a coil voltage of twenty-four VDC. It features a three-pole configuration and uses screw terminals for easy wiring. This contactor is suitable for various applications, including control circuits for motors and other electrical equipment.

• Rated for 12A maximum load current
• Designed for DIN rail or panel mounting
• Temperature range from -25 to 50 degrees Celsius

Product Highlights

This contactor is ideal for controlling motors in industrial and commercial settings.

Product Information

Standard Information

• Brand: Eaton
• Model Number: XTCE012B10TD

Technical Specifications

• Coil Voltage: 24 VDC
• Number of Poles: 3
• Coil Power Rating: 1 hp at 115 VAC
• Application: Electrical Assemblies, Panels and EOEMs
• Weight: 0.5 lb
• Dimensions: 1.77 inches (width) x 2.95 inches (depth) x 2.68 inches (height)
• Standards: IEC 60947, CSA Certified, UL Listed, RoHS Compliant
