EATON XTCE012B01T B-Frame Full Voltage Non-Reversing IEC Contactor 24 VAC at 50/60 Hz

Product Description

The EATON XTCE012B01T is a B-Frame full voltage non-reversing IEC contactor, designed for various industrial applications. This device operates with a coil voltage of twenty-four VAC at 50/60 Hz and supports a maximum load current of twelve A.

• Coil Power Rating: 1 hp at 115 VAC 1 ph, 2 hp at 200/230 VAC 1 ph, 3 hp at 200/230 VAC 3 ph, 10 hp at 460/575 VAC 3 ph.
• Features an IP20 enclosure, making it suitable for various environments.
• Compact dimensions of 1.77 inches wide, 2.95 inches deep, and 2.68 inches high.

Product Highlights

This contactor is part of the XT IEC Series and is designed for energy efficiency and space-saving installation.

Product Information

Standard Information

• Manufacturer: EATON
• Part Number: XTCE012B01T

Technical Specifications

• Size: 45 mm
• Type: B-Frame Full Voltage Non-Reversing
• Coil Voltage: 24 VAC at 50/60 Hz
• Maximum Load Current: 12 A
• Number of Poles: 3
• Contact Configuration: 1NC
• Operating Temperature: -13 to 122 degrees F
• Mounting Type: DIN Rail/Panel
• Enclosure Type: IP20
• Auxiliary Contacts: 1
• Frequency Rating: 50/60 Hz
• Dimensions: 1.77 in W x 2.95 in D x 2.68 in H
