Eaton XBUK10FBCN Fuse Terminal Block 6-AWG 20-4-AWG IEC 60 947-7-3 20-6-AWG IEC 60 947-7-3 22-6-AWG UL-cUL

Product Description

Eaton Fuse Terminal Block XBUK10FBCN is designed to handle a voltage rating of eight hundred volts and a current rating of twenty amps. This terminal block can accommodate conductor sizes ranging from twenty-two to six AWG and is mounted on DIN rails. It is suitable for use with six point three millimeters by thirty-two millimeters fuses and adheres to UL and CSA standards.

• Voltage rating of 800 volts
• Current rating of 20 amps
• DIN rail mountable

Product Highlights

This product ensures secure connections in electrical installations.

Product Information

Standard Information

• Brand: Eaton
• Country of Origin: Germany

Technical Specifications

• MPN: XBUK10FBCN
• UPC: 78211692564
• UNSPSC: 39121410
• Mounting: 35 mm DIN Rail
• Voltage Rating: 800 Volt (IEC 60 947-7-3), 300 Volt (UL/cUL)
• Conductor Range: 6 AWG, 20-4 AWG IEC, 20-6 AWG IEC, 22-6 AWG UL-cUL
• Amperage Rating: 10 Amp (IEC 60 947-7-3), 20 Amp (UL/cUL)
• Color: Black
• Wire Strip Length: 0.43 inch
