Eaton WMZS3C06 Supplementary protector 6 A (3 Pole)

Product Description

Eaton WMZS3C06 is a 3-pole supplementary protector that provides current limiting overcurrent protection for circuits where branch protection is separate. The device is rated 6 A and 277/480 VAC with a 10 kA interrupting rating, thermal/magnetic trip, and C-curve characteristics. It mounts to a DIN rail, accepts 18 to 8 AWG wiring, and is constructed of nylon for panel integration in industrial and commercial electrical systems.

• Current limiting design, 6 A rating, 10 kA interrupting capability for fast short circuit interruption
• Thermal/magnetic trip with C-curve behavior; toggle actuator and standard box connection
• DIN rail mounting; accepts 18 to 8 AWG; operating temperature -40 to 75 deg C; dimensions 2.07 x 3.01 x 3.15 in

Product Highlights

Supplementary, current-limiting overcurrent protection for 3-pole circuits in industrial and commercial panels

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: WMZS3C06
