Eaton WMZS1D32 Supplementary Protector 32 A (1 Pole) FAZ-D32-1-SP

Product Description

Eaton WMZS1D32 is a WMZS series supplementary protector that provides current-limiting overcurrent protection per UL 1077. The 1-pole thermal/magnetic device is rated 32 A for 277/480 VAC service, features a 10 kA interrupt rating, DIN-rail mounting, and standard box terminal connections for 18 to 8 AWG conductors. Operating range is -40 to 75 deg C and the housing is molded nylon with compact dimensions.

• Current-limiting thermal/magnetic protection, 32 A rating with 10 kA interrupt capacity
• DIN-rail mounting with standard box terminal connections accepting 18 to 8 AWG wire
• Compact nylon enclosure, operating temperature -40 to 75 deg C, dimensions 0.69 in x 3.01 in x 3.15 in

Product Highlights

UL 1077 supplementary protector, current limiting, 32 A, 277/480 VAC, 10 kA interrupt, 1 pole, DIN-rail mount

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: WMZS1D32
• Country of Origin: United States
