Description

Product Description

Eaton WMZS1D05 is a WMZS series supplementary protector that provides thermal-magnetic, current-limiting overcurrent protection with a D trip curve and a 5 A rating. Recognized to UL 1077, it supports 277/480 VAC and 48 VDC systems, with a listed interrupting capacity of 10 kA and a trip range of 10 to 20 times rating. The unit mounts on DIN rail, uses screw terminals and a toggle actuator, and accepts 18 to 8 AWG conductors.

  • Thermal-magnetic, current-limiting design with D trip characteristic and 5 A rating; UL 1077 recognized
  • Rated for 277/480 VAC and 48 VDC, listed interrupting capacity 10 kA, trip range 10 to 20 times rating
  • DIN rail mount, toggle actuator, standard box screw terminals, accepts 18 to 8 AWG, operating -40 to 75 deg C

Product Highlights

1-pole DIN-rail supplementary protector, 5 A, D-curve thermal-magnetic trip, 10 kA interrupt, UL 1077 recognized

Product Information

Standard Information

  • Brand: EATON
  • Manufacturer Part Number: WMZS1D05
  • Country of Origin: China
Technical Specifications
Brand
Eaton
Manufacturer Part Number
WMZS1D05
Series
WMZS
Product Type
Supplementary protector (UL1077)
Trip Characteristic
Thermal-magnetic, D curve
Poles
1
Current Rating
5 A
Voltage Rating (AC)
277/480 VAC
Voltage Rating (AC alternative)
230/400 VAC
DC Rating
48 VDC
Interrupt Rating
10 kA
Alternate Interrupt Rating
5 kA (as listed in some sources)
Trip Range
10-20 x rating
Mounting Type
DIN Rail
Actuator Type
Toggle lever
Connection Type
Standard box
Terminals
Screw
Wire Size
18 to 8 AWG
Material
Nylon
Operating Temperature
-40 to 75 deg C
Standards/Certifications
UL 1077 recognized; CSA C22.2 No. 235; IEC/EN 60947-2; IEC/EN 60898
UL Recognized File #
E162396
CSA File #
245545
RoHS
No
Retired
June 2015
Direct Replacement Part
FAZ-D5-1-SP
Weight
0.22 lbs
Special Features
Current limiting design; trip-free operation; contact position indicator (red/green); captive screws; field-installable shunt trip and auxiliary switch; 17.7 mm module width per pole
Dimensions (L x W x H)
0.69 in x 3.15 in x 2.36 in
