Eaton TWRBR20WBXSP Tamper Resistant Outlet 15A 125V

Product Description

The EATON TWRBR20WBXSP is a tamper resistant duplex receptacle rated at 15 amps and 125 volts, designed for residential and light commercial electrical installations. Tamper resistant receptacles feature spring-loaded shutters that block foreign objects from being inserted into the slots while allowing standard plug prongs to engage normally. This construction meets National Electrical Code requirements for tamper resistant protection in dwelling units. Licensed electricians install this device in standard wall boxes during new construction or retrofit projects.

This receptacle is suited for general-purpose branch circuit wiring in residential occupancies including bedrooms, living areas, hallways, and other spaces where NEC tamper resistant requirements apply. It is also appropriate for light commercial applications where code-compliant tamper resistant devices are specified. The white finish integrates with standard decorator and conventional wallplate configurations.

Key Features

• Tamper resistant shutters meet NEC dwelling unit requirements for child protection
• 15 amp, 125 volt rating for standard branch circuit applications
• Duplex configuration provides two outlets per device
• White finish compatible with standard wallplates
• Suitable for residential new construction and retrofit installations

Compatibility

Designed as an OEM-style replacement or new-installation duplex receptacle for standard single-gang wall boxes used in residential and light commercial branch circuit wiring.

Installation Notes

Installation should be performed by a licensed electrician in accordance with the National Electrical Code and applicable local codes. Always shut off the branch circuit breaker and verify the circuit is de-energized with a non-contact voltage tester before wiring the device. Secure the receptacle to the wall box using the provided mounting screws and install an appropriate wallplate before restoring power.

Technical Specifications

• Amperage: 15 amps
• Voltage: 125 volts
• Configuration: Duplex
• Tamper Resistant: Yes
• Color: White
• UPC: 03266475029

Standard Information

• Brand: EATON
• Manufacturer Part Number: TWRBR20WBXSP
