Eaton TWRBR15B CWD Tamper & Weather Resistant 15A-125V Duplex Recept

Product Description

The EATON TWRBR15B Arrow Hart Straight Blade Receptacle is a duplex receptacle designed for commercial applications. Rated at 125V and 15A, this 2-pole, 3-wire receptacle features a 5-15R NEMA rating and back/side wire screw terminals. Its durable nylon construction ensures longevity.

• Nickel plated brass contacts
• Flush mounting
• Tamper and weather resistant

Product Highlights

This Eaton duplex receptacle is ideal for commercial settings requiring a robust and reliable power connection. It offers tamper and weather resistance for added safety and durability.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: TWRBR15B

Technical Specifications

• Amperage Rating: 15 A
• Application: Commercial
• Grade: Commercial
• Manufacturer Part Number: TWRBR15B
• Material: Nylon
• NEMA Rating: 5-15R
• Number of Poles: 2
• Number of Wires: 3
• Series: TWRBR
• Standards/Approvals: NOM Certified|cULus Listed
• Terminal Type: Back/Side Wire/Screw
• Type: Duplex
• Voltage Rating: 125 V
• Product Length/Depth: 1.3 in
• Product Height: 4.19 in
• Product Width: 1.09 in
• Certifications: cULus Listed NOM
• Product Type: Commercial specification grade
• Device type: Receptacle
• Contact material: Nickel plated brass
• Features: Tamper resistant Weather resistant Auto-grounding
• Device grade: Commercial
• Wiring method: Back and side
• Environmental conditions: Damp/wet
• Mounting method: Flush
• Number of poles: Two-pole
• Style type: Standard
• Packaging type: Core pack
• Environmental resistance: Weather resistant
• Connection type: Screw
• Allowable wire size: Side or Back Wiring :#10-14 Copper or Copper Clad Aluminum
• Torque rating: 14 lbf-inch
• Design type: Straight blade
• Face/body material: Impact-resistant nylon face Glass-filled nylon base
• Receptacle type: Duplex
• Current Rating: 15 A
• Voltage: 125 VAC
• Watertight: No
• Isolated Ground: No
• Illuminated: No
• Special Properties: Tamper Resistant
• Approvals: cULus
