Product Description
The Eaton TRSGF15LA wiring self-test tamper resistant GFCI receptacle measures 4.2 in L x 1.68 in W x 1.27 in D and is automatic. This GFCI receptacle provides protection from dangerous electrical shocks caused by ground faults. It conducts an automatic self-test periodically to ensure GFCI protection.
- Self-Test
- Tamper Resistant
- GFCI Receptacle
Product Highlights
The Eaton TRSGF15LA GFCI receptacle provides protection from electrical shocks and automatically self-tests for safety.
Product Information
Standard Information
-
Brand: EATON
-
Manufacturer Part Number: TRSGF15LA
-
Country of Origin: CHN
Technical Specifications
-
Voltage: 125 Volts
-
Certification: UL
-
Amperage Capacity: 15 Amps
-
Batteries Included?: No
-
Batteries Required?: No
-
Total Power Outlets: 2
-
Brand: Eaton
-
Model / MPN: TRSGF15LA
-
Number of Items: 1.0
-
Product Type: ELECTRICAL_OUTLET
-
Frequency Rating: 60 Hz
-
Grade: Specification
-
Material: Nylon
-
NEMA Rating: NEMA 5-15R
-
Number of Poles: 2
-
Number of Wires: 3
-
Series: TRSGF
-
Standards/Approvals: cULus Listed|NOM 426 Certified|UL 498|UL 943|E60120 Listed|CSA Certified
-
Temperature Rating: -35 to 66 deg C
-
Terminal Type: Back/Side Wire
-
Type: Tamper-Resistant
-
Voltage Rating: 125 VAC
-
Amperage Rating: 15A
-
Device type: Receptacle
-
Circuit interrupter type: GFCI
-
Contact material: Brass
-
Features: Tamper resistant
-
Application: ResidentialCommercial
-
Wiring method: Back and side wire
-
Allowable wire size: #14 - 10 AWG
-
NEMA configuration: 5-15R
-
Torque rating: 16 lbf-inch
-
Environmental conditions: Tamper resistant
-
Mounting method: Flush
-
Face/body material: PVC, Polycarbonate
-
Receptacle type: Two-pole, three-wire, grounding
-
Power Plug Type: Type A - 2 pin (North American)
-
Amperage: 15A
-
Connector Type: Nema 5-15
-
Specification Met: UL
-
Model: TRSGF15LA
-
Material Type: Copper
-
Unit Count: 1 Count
-
Current Type: AC
-
Thermoplastic: Thermoplastic
-
Maximum Amperage: 15A
-
Outlet Style: Double
-
Number of Gangs: 1
-
Additional Features: Self-Testing
-
Commercial Specification Grade: Commercial Specification Grade
-
Ground: GFCI Ground Fault
-
Lot Quantity: 1
-
Phase: 1 Phase
-
Poles: 2
-
Terminal Type(s): Back and Side Wired
-
Wires: 3
-
Country/Region of Manufacture: Unknown
-
Mounting Type: Mounting Strap
-
Termination Type: Terminal Screws
-
Quantity: 1
-
Gender: Female
-
Installation Area: Indoor
