Eaton TRL27 7-function universal TR series timing relay, 12-240 Vac/dc input voltage, Compact DIN rail mount, DPDT contact configuration

Product Description

The Eaton TRL27 is a 7-function universal timing relay designed for efficiency and versatility. It operates with an input voltage range of twelve to two hundred forty volts AC/DC and is ideal for controlling electrical assemblies and panels. The relay features a compact DIN rail mountable design for easy installation in various environments. It supports a time delay from zero point zero five seconds to one hundred hours, making it versatile for different applications.

• 7-function operation for flexible timing needs.
• Input voltage of 12 to 240 Vac/dc suitable for a variety of applications.
• Compact design that saves space in control panels.

Product Highlights

This timing relay is equipped with an advanced LED indication for easy troubleshooting and maintenance. Its DPDT contact configuration and IP40-rated enclosure provide reliability in diverse operational conditions.

Product Information

Standard Information

• Brand: Eaton
• MPN: TRL27

Technical Specifications

• Catalog Number: TRL27
• Type: 4-Function Compact Universal
• Voltage Rating: 12 to 240 Vac/dc
• Amperage Rating: 8 A
• Contact Configuration: DPDT
• Dimensions: 2.56 inches L x 1.38 inches W x 3.43 inches H
• Frequency Rating: 50-60 Hz
• Mounting Type: DIN Rail
• Standards: CSA Certified, cULus Listed, TUV, CE Marked
• Country of Origin: Austria
