Eaton T30100-3CR Bus fuse class T 61-100 A 300 Vac/Vdc (3 pole)

Product Description

The Eaton T30100-3CR is a Class T modular open fuse block rated 61 to 100 A and 300 VAC/VDC. It provides three-pole protection with a box lug connection for 1/0 AWG copper or aluminum conductors and a reinforced spring for secure contact. Constructed of glass polyester, it has a 200 kA rms interrupt rating, accepts JJN series cartridge fuses, and measures 4.78 in L x 4.5 in W x 2.06 in H with fuse length 2.16 in and diameter 3/4 in.

• Three-pole Class T modular open fuse block with box lug connection and reinforced spring
• Rated 61–100 A, 300 VAC/VDC with 200 kA rms interrupting capacity
• Constructed of glass polyester; overall 4.78 in L x 4.5 in W x 2.06 in H; accepts JJN series fuses

Product Highlights

Class T, 3-pole modular fuse block; 61–100 A, 300 VAC/VDC; 200 kA rms interrupt rating; accepts 1/0 AWG Cu/Al

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: T30100-3CR
