Eaton T-1-8/10 Type T plug fuse 1-8/10 A (Edison Plug)

Product Description

Eaton T-1-8/10 is a time-delay (slow-blow) plug fuse rated 1-8/10 A at 125 VAC designed for threaded Edison-base holders. It uses dual-element construction to tolerate inrush currents and provides a 10 kA interrupt rating for circuit protection. The fuse has a plastic body with a brass thread and is intended for electrical and industrial inline or holder-mounted applications.

• Time-delay (dual-element) plug fuse rated 1-8/10 A at 125 VAC
• 10 kAIC (RMS symmetrical) interrupt / 10 kA short-circuit rating
• Threaded Edison-base mounting with plastic body and brass thread

Product Highlights

Dual-element, time-delay Edison plug fuse; 1-8/10 A at 125 VAC; 10 kA interrupt rating; threaded Edison mounting.

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: T-1-8/10

Technical Specifications

• Brand: EATON
• Manufacturer Part Number: T-1-8/10
• Series: Type T
• Fuse Type: Plug fuse, time delay (slow blow)
• Current Rating: 1-8/10 A
• Voltage Rating: 125 VAC
• Interrupt Rating: 10 kAIC (RMS symmetrical)
• Short Circuit Rating: 10 kA
• Breaking Capacity: 10 kA @ rated voltage
• Mounting Type: Threaded mount (Edison base)
• Element: Dual element
• Body Material: Plastic
• Thread Material: Brass
• Base: Edison base
• Response Time: Time delay / Slow blow
• Applications: Electrical, Industrial
• RoHS Status: RoHS Compliant
• Weight: 29.48 g
