Eaton SPHM3RM0010 Medium Time Delay Supplementary Protector 10 A (3 Pole)

Product Description

Eaton SPHM3RM0010 is a 10 A hydraulic-magnetic supplementary protector listed to UL1077. The 3-pole device provides overcurrent protection for 277/480 VAC systems with a 3 kA interrupting capacity and operates at 50/60 Hz. It uses a medium time-delay hydraulic magnetic trip, cable-in/cable-out connections for 14 to 6 AWG conductors, DIN-rail mounting and an IP20 enclosure rated -40 to 85 deg C and measures 2.22 x 2.32 x 4.14 in.

• 10 A hydraulic-magnetic medium time-delay supplementary protector; UL1077 listed; 3-pole, 3 kAIC; 277/480 VAC, 50/60 Hz
• Cable-in/cable-out connections for 14 to 6 AWG; DIN-rail mounting with IP20 enclosure
• Operating temperature -40 to 85 deg C; dimensions 2.22 in L x 2.32 in W x 4.14 in H

Product Highlights

Hydraulic-magnetic 3-pole supplementary protector, UL1077, 10 A, 277/480 VAC, 3 kAIC

Product Information

Standard Information

• Brand: EATON
• Manufacturer Part Number: SPHM3RM0010
