Eaton S506-5-R Fuse

Product Description

The EATON S506-5-R is a fuse designed to provide overcurrent protection in electrical circuits. Fuses in this series are typically installed in control panels, industrial equipment, and low-voltage distribution systems where reliable circuit protection is required. Licensed electricians and qualified technicians handle installation during both new construction and service work. The compact form factor keeps panel space requirements low while delivering consistent interrupting performance under fault conditions.

This fuse is suited for use in residential, commercial, and light industrial electrical systems. It fits standard fuse holders and blocks commonly found in control circuits and branch-circuit protection applications. Its small size makes it appropriate for tight panel installations where space and weight are considerations.

Key Features

• Overcurrent protection for low-voltage control and branch circuits
• Compact, lightweight form factor at approximately 0.002 pounds
• Designed to fit standard compatible fuse holders and blocks
• Consistent interrupt performance under fault conditions

Compatibility

Designed as an OEM-style replacement fuse for use in standard fuse holders and blocks compatible with the S506 series form factor.

Installation Notes

Installation should be performed by a licensed electrician or qualified technician in accordance with the National Electrical Code (NEC). De-energize and lock out the circuit before replacing any fuse. Verify the replacement fuse rating matches the circuit requirements before installation. Never substitute a fuse with a higher amperage rating than specified by the equipment manufacturer.

Technical Specifications

• Weight: 0.002 pounds
• UPC: 05171263978

Standard Information

• Brand: EATON
• Manufacturer Part Number: S506-5-R
