Eaton S20N11S15N Type EP XFMR 15KVA Power Distribution Transformer 240/480V 120/240V

Product Description

The Eaton S20N11S15N is a general-purpose encapsulated transformer. It is designed for voltage transformation in various power distribution applications. This model operates with a primary voltage of two hundred forty to four hundred eighty volts and a secondary voltage of one hundred twenty to two hundred forty volts. The transformer is suitable for indoor or outdoor use.

• Single-phase operation with a capacity of fifteen kVA.
• Encapsulated design prevents moisture and contaminants.
• Meets ANSI, NEMA, and IEEE standards for safety and performance.

Product Highlights

This transformer offers robust functionality for commercial and institutional buildings. It is designed for continuous operation and can handle various loads.

Product Information

Standard Information

• Brand: Eaton
• Manufacturer: Eaton

Technical Specifications

• Catalog Number: S20N11S15N
• Type: Encapsulated Transformer
• Power Rating: 15 kVA
• Primary Voltage: 240/480 VAC
• Secondary Voltage: 120/240 VAC
• Frequency: 60 Hz
• Number of Phases: 1
• Frame Size: 180
• Dimensions: 10.52 in L x 13.38 in W x 19 in H
• Weight: 210 lb
